Frame set
frame KELLYS TAYEN RS-series - Superlight design, advanced robotic welded Al 6061-T6 / Designed & manufactured in EUROPE / integrated removable battery, 1.5“ tapered HT, 12x148 mm Boost thru axle
fork SR SUNTOUR XCM32 AIR LOR DS (27.5") Boost, 120 mm, air / Speed Lockout / 15 mm thru axle
frame size S
Drive
motor PANASONIC GXM, max torque 100 Nm
battery KELLYS K2 AMXXPRO CARBON 725 Wh - superhigh energy density 213 Wh/kg, weight 3.4 kg, capacity 20 Ah, co-developed by KELLYS-BMZ
switch unit PANASONIC
computer display PANASONIC GXM Center Display 501 - Bluetooth® 5.0 navigation, PANASONIC App conectivity
crankset MIRANDA Delta (36T) - length 170 mm
rear derailleur SHIMANO Cues U4000 (direct mount)
shifters SHIMANO Cues SL-U4000-9R Rapidfire Plus
speed 9
cassette sprocket SHIMANO Linkglide CS-LG300-9 (11-46T)
chain SHIMANO Linkglide CN-LG500
pedals plastic
Brakes
brakes SHIMANO MT200 Hydraulic Disc
brake levers SHIMANO BL-MT200
brake rotors GALFER Fixed Disc Wave® DB03W Center Lock, 180 mm front / 180 mm rear
Wheels
hubs SHIMANO TC500-15-B / TC500-HM-B Disc Center Lock (32 holes)
rims KLS Draft 23 Disc 584x23 (32 holes)
spokes stainless steel black
tyres SCHWALBE Smart Sam Active Line 57-584 (27.5"x2.25) K-Guard
thru axle SR SUNTOUR 15x110 mm front
Cockpit
head parts ACROS 1.8" tapered semi-integrated
stem KLS Active - diam 28.6 mm / bar bore 31.8 mm / délka 50 mm
handlebar KLS Active RiseBar - diam 31.8 mm / rise 18 mm / width 720 mm
grips KLS Poison OneLockon
seat post KLS Active - diam 30.9 mm / length 400 mm
saddle KLS Ascend
