Frame set
frame KELLYS THEOS R-series - advanced robotic welded 6-series aluminium alloy / Designed & manufactured in EUROPE / Think Link® suspension system, 130 mm rear travel, integrated removable battery, 1.8" tapered HT, post mount 203 mm, mullet 29" / 27.5"+ wheelset, 12x148 mm Boost thru axle
fork ROCK SHOX Psylo Silver RC (29") Boost, 150 mm, Solo Air / Motion Control / Maxle Stealth 15 mm thru axle
rear shock ROCK SHOX Deluxe Select R, DebonAir+ (210x55 mm)
frame size S / M / L
Drive
motor PANASONIC GX Ultimate, 95 Nm, 36 V
battery KELLYS Re-Charge K1 Li-ion internal removable 820 Wh / capacity 23 Ah, co-developed by KELLYS-BMZ
switch unit PANASONIC
computer display PANASONIC Bluetooth® 5.0 navigation Side Color Display
crankset MIRANDA Miranda (34T) - length 170 mm
rear derailleur SHIMANO Cues U6000 (direct mount)
shifters SHIMANO Cues SL-U6000-10R Rapidfire Plus
speed 10
cassette sprocket SHIMANO Linkglide CS-LG300-10 (11-48T)
chain SHIMANO Linkglide CN-LG500 (122 links)
Brakes
brakes SHIMANO MT420 / MT410 Hydraulic Disc
brake levers SHIMANO Deore BL-M4100
brake rotors SHIMANO RT30 203 mm front / 203 mm rear
Wheels
hubs SHIMANO MT400-B Disc Center Lock (15x110 mm / 12x148 mm / 32 holes)
rims KLS Asesino 30 Disc 622x30 / 584x30 (32 holes)
spokes stainless steel black
thru axle ROCK SHOX Maxle Stealth 15x110 mm front / 12x177 mm rear
rear tyre SCHWALBE Nobby Nic Performance 62-584 (27.5"x2.40) ADDIX, folding
front tyre SCHWALBE Nobby Nic Performance 62-622 (29"x2.40) ADDIX, folding
Cockpit
head parts ACROS 1.8 tapered semi-integrated
stem KLS CNC - diam 28.6 mm / bar bore 35 mm / length 35 mm
handlebar KLS Alm/En RiseBar - diam 35 mm / rise 18 mm / width 780 mm
grips KLS Poison OneLockon
seat post LIMOTEC A1 Remote Telescopic - diam 30.9 mm / length 445 mm, travel 150 mm
saddle SELLE ROYAL SRX
We reserve the right to make changes to the product information contained on this site at any time without notice, including on equipment, specifications, models, colours, and materials.
