Frame set
frame KELLYS Dirt DX 26", tapered HT, ISCG 05
fork SR SUNTOUR XCM DS (26"), 100 mm, coil spring
frame size M / L
Drive
crankset SAMOX (32T) - length 170 mm
rear derailleur microSHIFT Acolyte M5180
front derailleur
chain guide MOZARTT Presto, ISCG 05
shifters microSHIFT Acolyte SL-M6180-R
speed 8
cassette sprocket microSHIFT Mezzo CS-H081-8 (11-34T)
chain KMC Z8
b.b.parts cartridge (126.5 mm)
pedals plastic platform
Brakes
brakes Mechanical Disc
brake levers APSE
brake rotors 160 mm front / 160 mm rear
Wheels
hubs KLS Firework Disc (32 holes)
rims KLS Draft Disc 559x21 (32 holes)
spokes steel
tyres KENDA Small Block Eight 58-559 (26"x2.35)
Cockpit
head parts semi-integrated
stem KLS CNC - diam 28.6 mm / bar bore 35 mm / length 35 mm
handlebar KLS Active RiseBar - diam 31.8 mm / rise 18 mm / width 760 mm
grips kraton
seat post KLS Active - diam 30.9 mm / length 300 mm (S - M)
saddle KLS Vader
