Frame set
frame
KELLYS Alutec RRC 26" - Race Ready Concept, 1.5" tapered HT
fork
SR SUNTOUR XCE28 DS (26"), 100 mm, coil spring
frame size
XXS / XS
Drive
crankset
PROWHEEL (32T) - length 165 mm (XXS - XS)
rear derailleur
microSHIFT Estes M220
shifters
microSHIFT Estes TS200-8R
speed
8
cassette sprocket
microSHIFT M680-8 (11-42T)
chain
KMC Z8
b.b.parts
cartridge (122 mm)
pedals
plastic
Brakes
brakes
SHIMANO MT200 Hydraulic Disc
brake levers
SHIMANO BL-MT200
brake rotors
160 mm front / 160 mm rear
Wheels
hubs
SHIMANO QC300 Disc Center Lock (32 holes)
rims
KLS Draft 23 Disc 559x23 (32 holes)
spokes
steel
tyres
WTB Nano Comp 52-559 (26"x2.10)
Cockpit
head parts
1.5" semi-integrated
stem
KLS Active - diam 28.6 mm / bar bore 31.8 mm / length 60 mm (XXS - XS)
handlebar
KLS Active RiseBar - diam 31.8 mm / rise 18 mm / width 640 mm (XXS - XS)
grips
KLS Advancer
seat post
KLS Active - diam 30.9 mm / length 350 mm (XXS - XS)
saddle
KLS Ascend
weight
13.44 kg (XS)
