Frame set
frame
KELLYS Alutec RRC 29 - Race Ready Concept
fork
SR SUNTOUR XCM HLO (29), 100 mm, coil / Speed Lockout
frame size
M / L / XL
Drive
crankset
SHIMANO TY501 (42x34x24T) - length 175 mm
rear derailleur
SHIMANO Altus M310 (direct mount)
front derailleur
SHIMANO TY700 (34.9 mm)
shifters
SHIMANO SL-M310 Rapidfire Plus
speed
24
cassette sprocket
SHIMANO CS-HG200-8 (11-32T)
chain
KMC Z8
b.b.parts
cartridge (122 mm)
pedals
alloy
Brakes
brakes
SHIMANO MT200 Hydraulic Disc or KLS 1600 Hydraulic Disc
brake levers
SHIMANO BL-MT200 or KLS 1600
brake rotors
160 mm front / 160 mm rear
Wheels
hubs
KT Disc / SHIMANO TX505 Disc Center Lock or KT Disc Center Lock (32 holes)
rims
KLS Draft Disc 622x21 (32 holes)
spokes
steel
tyres
IMPAC Ridgepac or INNOVA 54-622 (29x2.10)
Cockpit
head parts
semi-integrated
stem
KLS Active - diam 28.6 mm / bar bore 31.8 mm / 8° / length 75 mm (M), 90 mm (L - XL)
handlebar
KLS Active RiseBar - diam 31.8 mm / rise 18 mm / width680 mm
grips
KLS Advancer
seat post
KLS Active - diam 30.9 mm / length 300 mm (M), 350 mm (L - XL)
saddle
KLS Sentinel 2
