Frame set
frame KELLYS Alutec RRC 27.5 - Race Ready Concept
fork SR SUNTOUR XCE28 (27.5), 100 mm, coil spring
frame size S / M
Drive
crankset SHIMANO TY301 (42x34x24T) - length 170 mm (S), 175 mm (M)
rear derailleur SHIMANO TX800 (direct mount)
front derailleur
SHIMANO TY700 (34.9 mm)
shifters SHIMANO ST-EF510-8 EZ-fire Plus
speed 24
cassette sprocket SHIMANO CS-HG200-8 (11-32T)
chain KMC Z8 (108 links)
b.b.parts cartridge (122 mm)
pedals alloy
Brakes
brakes Mechanical Disc
brake levers SHIMANO ST-EF510 EZ-fire Plus
brake rotors 160 mm front / 160 mm rear
Wheels
hubs KLS Firework Disc (32 holes)
rims KLS Draft Disc 584x21 (32 holes)
spokes steel
tyres IMPAC Ridgepac 54-584 (27.5x2.10)
Cockpit
head parts semi-integrated
stem KLS Active - diam 28.6 mm / bar bore 31.8 mm / 8° / length 75 mm
handlebar KLS Active RiseBar - diam 31.8 mm / rise 18 mm / width 660 mm (S), 680 mm (M)
grips KLS Advancer
seat post KLS Active - diam 30.9 mm / length 300 mm (S - M)
saddle KLS Sentinel 2
