Frame set
frame KELLYS e-FRAME Tour Profile Aluminium alloy, semi-integrated battery, tapered HT, integrated kickstand mount
fork SR SUNTOUR NVX 30 NLO DS (29), 80 mm, coil spring
frame size M / L
Drive
motor SHIMANO STEPS E5000, 36 V
battery SHIMANO BT-E8016, 630 Wh / capacity 17.5 Ah
computer display SHIMANO SC-E5000 cycle computer with assist switch
crankset SHIMANO E5000 (38T) - length 170 mm
rear derailleur SHIMANO Cues U4000 or SHIMANO Altus M2000 (direct mount)
shifters SHIMANO Cues SL-U4000-9 or SHIMANO Altus SL-M2000 Rapidfire Plus
speed 9
cassette sprocket SHIMANO Linkglide CS-LG300-9 (11-41T) or SHIMANO CS-HG201-9 (11-36T)
chain SHIMANO Linkglide CN-LG500 (122 links)
pedals plastic
Brakes
brakes SHIMANO MT200 Hydraulic Disc
brake levers SHIMANO BL-MT200
brake rotors 160 mm front / 160 mm rear
Wheels
hubs SHIMANO TX505 Disc Center Lock (32 holes)
rims KLS Draft Disc 622x21 (32 holes)
spokes stainless steel black
tyres IMPAC Bigpac 55-622 (28x2.15) TwinSkin or KENDA Kwick Nine (29x2.0) - ReflectiveLine
fenders
plastic
Cockpit
head parts FSA 1.5 semi-integrated
stem PROMAX a-head adjustable - diam 28.6 mm / bar bore 31.8 mm / length 105 mm
handlebar KALLOY RiseBar - diam 31.8 mm / width 640 mm
grips KLS Wave 2Density ergonomic
seat post KLS Active - diam 30.9 mm / length 350 mm
saddle SELLE ROYAL Vivo
front light
AXA Compactline 35
rear light
TRELOCK Duo Flat
accessories
alloy carrier, adjustable kickstand, bell
