Frame set
frame KELLYS TAYEN R series - advanced robotic welded 6-series aluminium alloy, integrated removable battery, 1.5“ tapered HT, 12x148 mm Boost thru axle / Made in EU
fork ROCK SHOX Recon Silver RL (29) Boost, 120 mm, Solo Air / Motion Control / Maxle Stealth 15 mm thru axle
frame size M / L
Drive
motor SHIMANO STEPS E7000, 36 V
battery KELLYS Re-Charge V10 Li-ion internal removable 725 Wh / capacity 20 Ah, powered by BMZ
computer display SHIMANO SC-E5000 cycle computer with assist switch
crankset SHIMANO E6100 (34T) - length 170 mm
rear derailleur SHIMANO Deore M5120 (direct mount)
shifters SHIMANO Deore SL-M4100-R Rapidfire Plus (I-Spec EV)
speed 10
cassette sprocket SHIMANO CS-M4100-10 (11-46T)
chain KMC e10T (116 links)
Brakes
brakes SHIMANO MT200 Hydraulic Disc
brake levers SHIMANO BL-MT200
brake rotors 180 mm front / 180 mm rear
Wheels
hubs SHIMANO MT400-B Disc Center Lock (15x110 mm / 12x148 mm / 32 holes)
rims KLS Valor 3 Disc 622x30 (32 holes)
spokes stainless steel black
tyres SCHWALBE Nobby Nic Performance 60-622 (29x2.40) ADDIX
thru axle ROCK SHOX Maxle Stealth 15x110 mm front / NOVATEC 12x148 mm rear
Cockpit
head parts FSA 1.5 semi-integrated
stem KLS Alm/En 50 - diam 28.6 mm / bar bore 31.8 mm / lenght 45 mm
handlebar KLS Active RiseBar - diam 31.8 mm / rise 18 mm / width 700 mm
grips KLS Poison OneLockon
seat post KLS Active - diam 30.9 mm / length 350 mm
saddle KLS Sentinel 2
We reserve the right to make changes to the product information contained on this site at any time without notice, including on equipment, specifications, models, colours, and materials.
