Frame set
frame KELLYS THEOS RS-series - Superlight design, advanced robotic welded Al 6061-T6 / Designed & manufactured in EUROPE / Think Link® suspension system, 140 mm rear travel, integrated removable battery, 1.8" tapered HT, post mount 203 mm, mullet 29 / 27.5"+ wheelset, 12x148 mm Boost thru axle
fork ROCK SHOX Recon Silver RL (29") Boost, 150 mm, Solo Air / Motion Control / Maxle Stealth 15 mm thru axle
rear shock ROCK SHOX Deluxe Select, DebonAir+ / R damper (210x55 mm)
frame size M / L
Drive
motor PANASONIC GXM, max torque 100 Nm
battery KELLYS K2 AMXXPRO CARBON 725 Wh - superhigh energy density 213 Wh/kg, weight 3.4 kg, capacity 20 Ah, co-developed by KELLYS-BMZ
switch unit PANASONIC
computer display PANASONIC GXM Center Display 501 - Bluetooth® 5.0 navigation, PANASONIC App conectivity
crankset MIRANDA Miranda (34T) - length 170 mm
rear derailleur SHIMANO Cues U4000 (direct mount)
shifters SHIMANO Cues SL-U4000-9R Rapidfire Plus
speed 9
cassette sprocket SHIMANO Linkglide CS-LG300-9 (11-46T)
chain SHIMANO Linkglide CN-LG500
pedals plastic
Brakes
brakes SHIMANO MT200 Hydraulic Disc
brake levers SHIMANO BL-MT200
brake rotors GALFER Fixed Disc Wave® DB034W Center Lock, 203 mm front / 203 mm rear
Wheels
hubs SHIMANO TC500-15-B / TC500-HM-B Disc Center Lock (32 holes)
rims KLS ASESINO 30 Disc 622x30 / 584x30 (32 holes)
spokes stainless steel black
thru axle predná ROCK SHOX Maxle Stealth 15x110 mm
rear tyre SCHWALBE Smart Sam 60-584 (27.5"x2.35) K-Guard
front tyre SCHWALBE Smart Sam 60-622 (29"x2.35) K-Guard
Cockpit
head parts ACROS 1.8" tapered semi-integrated
stem KLS Alm/En 30 - diam 28.6 mm / bar bore 35 mm / length 35 mm
handlebar KLS Alm/En 70 RiseBar - diam 31.8 mm / rise 25 mm / width 780 mm
grips KLS Advancer 2Density
seat post KLS Active - diam 30.9 mm / length 350 mm
saddle KLS Ascend
