Frame set
frame
KELLYS THEOS R-series - advanced robotic welded 6-series aluminium alloy / Designed & manufactured in EUROPE / Think Link® suspension system, 130 mm rear travel, integrated removable battery, 1.8" tapered HT, post mount 203 mm, mullet 29" / 27.5"+ wheelset, 12x148 mm Boost thru axle
fork
ROCK SHOX Recon Silver RL (29") Boost, 150 mm, SOLO Air+/ Maxle Stealth 15 mm thru axle
rear shock
ROCK SHOX Deluxe Select+ R, LinearAir+ (210x55 mm)
frame size
S / M / L
Drive
motor
PANASONIC GX Ultimate, 95 Nm, 36 V
battery
KELLYS Re-Charge K1 Li-ion internal removable 725 Wh / capacity 20 Ah, co-developed by Kellys-BMZ
switch unit
PANASONIC
computer display
PANASONIC Bluetooth® 5.0 navigation Side Color Display
crankset
MIRANDA Miranda (34T) - length 170 mm
rear derailleur
SHIMANO Cues U4000 (direct mount)
shifters
SHIMANO Cues U4010-9 Rapidfire Plus
speed
9
cassette sprocket
SHIMANO Linkglide CS-LG300-9 (11-46T)
chain
SHIMANO Linkglide CN-LG500
Brakes
brakes
SHIMANO MT200 Hydraulic Disc
brake levers
SHIMANO BL-MT200
brake rotors
SHIMANO RT10 180 mm front / RT10 180 mm rear
Wheels
hubs
SHIMANO TC500-B / Deore TC500-B Disc Center Lock (15x110 mm / 12x148 mm / 32 holes)
rims
KLS Asesino 30 Disc 622x30 / 584x30 (32 holes)
thru axle
ROCK SHOX Maxle Stealth 15x110 mm front / Mr. Control 12x177 mm rear
rear tyre
SCHWALBE Nobby Nic 62-584 (27.5"x2.40) ADDIX
front tyre
SCHWALBE Nobby Nic 62-622 (29"x2.40) ADDIX
Cockpit
head parts
ACROS 1.8 tapered semi-integrated
stem
KLS Alm/En 50 - diam 28.6 mm / bar bore 31.8 mm / length 60 mm
handlebar
KLS Alm/En 70 RiseBar - diam 31.8 mm / rise 25 mm / width 780 mm
grips
KLS Poison OneLockon
seat post
KLS Active - diam 30.9 mm / length 350 mm
saddle
SELLE ROYAL SRX
