Frame set
frame KELLYS Crossforce Lite - tapered HT, internal routing, integrated kickstand mount
fork SR SUNTOUR NVX30 NLO DS, 80 mm, coil / Speed Lockout
frame size M / L
Drive
crankset SHIMANO Acera T3010 (48x36x26T) - length 175 mm
rear derailleur SHIMANO Alivio M4000 (direct mount)
front derailleur
SHIMANO Acera T3000 (31.8 mm)
shifters SHIMANO Alivio SL-M4000 Rapidfire Plus
speed 27
cassette sprocket SHIMANO CS-HG300-9 (11-34T)
chain KMC X9 (114 links)
b.b.parts cartridge (124.5 mm)
pedals alloy
Brakes
brakes SHIMANO MT200 Hydraulic Disc or KLS 1600 Hydraulic Disc
brake levers SHIMANO BL-MT200 or KLS 1600
brake rotors 160 mm front / 160 mm rear
Wheels
hubs alloy / SHIMANO TX505 Disc Center Lock (32 holes)
rims KLS Draft Disc 622x21 (32 holes / eyelets)
spokes stainless steel black
tyres MICHELIN Protek Cross 42-622 (700x40C) ReflectiveLine
Cockpit
head parts semi-integrated
stem KLS CRX 70 adjustable - diam 28.6 mm / bar bore 31.8 mm / length 95 mm
handlebar KLS CRX 70 RiseBar - diam 31.8 mm / rise 25 mm / width 640 mm (M), 660 mm (L)
grips KLS Token 2Density
seat post KLS Active - diam 27.2 mm / length 350 mm
saddle SELLE ROYAL Vivo
We reserve the right to make changes to the product information contained on this site at any time without notice, including on equipment, specifications, models, colours, and materials.
