Frame set
frame KELLYS Crossforce Lite - tapered HT, internal routing, integrated kickstand mount
fork SR SUNTOUR NEX HLO DS, 63 mm, coil spring
frame size S / M / L / XL
Drive
crankset SHIMANO TY501 (48x38x28T) - length 170 mm (S), 175 mm (M - XL)
rear derailleur SHIMANO M370 (direct mount)
front derailleur
SHIMANO TY601 (34.9 mm)
shifters microSHIFT Marvo M859 Xpress Shifter
speed 27
cassette sprocket SHIMANO CS-HG200-9 (11-34T)
chain KMC X9 (114 links)
b.b.parts cartridge (122 mm)
pedals alloy
Brakes
brakes TEKTRO Hydraulic Disc
brake levers TEKTRO
brake rotors 160 mm front / 160 mm rear
Wheels
hubs KLS Firework Disc (32 holes)
rims KLS Draft Disc 622x21 (32 holes / eyelets)
spokes stainless steel
tyres INNOVA 44-622 (700x42C)
Cockpit
head parts semi-integrated
stem KLS Advanced - diam 28.6 mm / bar bore 31.8 mm / 7° / length 90 mm (S - L), 110 mm (XL)
handlebar KLS CRX 70 RiseBar - diam 31.8 mm / rise 25 mm / width 640 mm (S - M), 660 mm (L - XL)
grips KLS Token 2Density
seat post KLS Active - diam 30.9 mm / length 350 mm (S), 400 mm (M - XL)
saddle KLS
We reserve the right to make changes to the product information contained on this site at any time without notice, including on equipment, specifications, models, colours, and materials.
