Frame set
frame KELLYS Crosslite
fork SR SUNTOUR NEX HLO DS, 63 mm, coil / Speed Lockout
frame size S / M / L / XL
Drive
crankset SHIMANO TY501 (48x38x28T) - length 170 mm (S), 175 mm (M - XL)
rear derailleur SHIMANO Acera M3020-8 or Altus M370 (direct mount)
front derailleur
SHIMANO TY601 (31.8 mm)
shifters SHIMANO SL-M315-8R Rapidfire Plus
speed 24
cassette sprocket SHIMANO CS-HG200-8 (12-32T)
chain KMC Z8 (114 links)
b.b.parts cartridge (122 mm)
pedals alloy
Brakes
brakes TEKTRO Hydraulic Disc
brake levers TEKTRO
brake rotors 160 mm front / 160 mm rear
Wheels
hubs KLS Firework Disc (32 holes)
rims KLS Draft 23 Disc 622x23 (32 holes)
spokes stainless steel
tyres INNOVA 44-622 (700x42C)
Cockpit
head parts semi-integrated
stem KLS CRX 70 adjustable - diam 28.6 mm / bar bore 31.8 mm / length 95 mm (S - L), 110 mm (XL)
handlebar KLS CRX 70 RiseBar - diam 31.8 mm / rise 25 mm / width 640 mm (S - M), 660 mm (L - XL)
grips KLS Token 2Density
seat post KALLOY - diam 27.2 mm / length 350 mm
saddle KLS CrossLine
