Frame set
frame KELLYS E-CARSON R-series - advanced robotic welded 6-series aluminium alloy, integrated removable battery, 1.5“ tapered HT / Made in EU
fork SR SUNTOUR NVX30 NLO (29), 100 mm, coil spring
frame size M / L / XL
Drive
motor PANASONIC GX Ultimate, 90 Nm, 36 V
battery KELLYS Re-Charge V10 Li-ion internal removable 725 Wh / capacity 20 Ah, powered by BMZ
computer display PANASONIC Bluetooth® 5.0 navigation Side Color Display
crankset SAMOX (38T) - length 170 mm
rear derailleur SHIMANO Altus M2000 (direct mount)
shifters SHIMANO Altus SL-M2000 Rapidfire Plus
speed 9
cassette sprocket SHIMANO CS-HG201-9 or CS-GH400-9 (11-36T)
chain KMC e9S (118 links)
pedals plastic
Brakes
brakes SHIMANO MT200 hydraulic disc
brake levers SHIMANO BL-MT200
brake rotors 160 mm front / 160 mm rear
Wheels
hubs SHIMANO TX505 Disc Center Lock (32 holes)
rims KLS Draft Disc 622x21 (32 holes)
spokes stainless steel black
tyres IMPAC Bigpac TwinSkin or SCHWALBE Road Cruiser Plus 55-622 (28x2.15) ReflectiveLine
fenders
plastic
Cockpit
head parts FSA 1.5 semi-integrated
stem PROMAX a-head adjustable - diam 28.6 mm / bar bore 31.8 mm / length 105 mm
handlebar KLS Active RiseBar - diam 31.8 mm / rise 18 mm / width 700 mm
grips KLS Wave 2Density ergonomic
seat post KLS Active - diam 30.9 mm / length 350 mm
saddle SELLE ROYAL Vivo
front light
AXA Compactline 35
rear light
TRELOCK Duo Flat
accessories
alloy carrier, adjustable kickstand, bell
We reserve the right to make changes to the product information contained on this site at any time without notice, including on equipment, specifications, models, colours, and materials.
