Frame set
frame KELLYS Crossforce Lite - tapered HT, internal routing, integrated kickstand mount
fork SR SUNTOUR NEX HLO DS, 63 mm, coil spring
frame size M / L
Drive
crankset PROWHEEL (48x36x26T) - length 175 mm
rear derailleur SHIMANO Acera M3000 (direct mount)
front derailleur
SHIMANO TY710 (31.8 mm)
shifters SHIMANO ST-EF505-9 EZ-fire Plus
speed 27
cassette sprocket SHIMANO CS-HG200-9 alebo DTS-9 (11-34T)
chain KMC X9 (114 links)
b.b.parts cartridge (113 mm)
pedals alloy
Brakes
brakes SHIMANO MT200 Hydraulic Disc
brake levers SHIMANO ST-EF505-9 EZ-fire Plus
brake rotors 160 mm front / 160 mm rear
Wheels
hubs SHIMANO TX505 Disc Center Lock (32 holes)
rims KLS Draft Disc 622x21 (32 holes / eyelets)
spokes stainless steel black
tyres INNOVA 44-622 (700x42C)
Cockpit
head parts semi-integrated
stem KLS CRX 70 adjustable - diam 28.6 mm / bar bore 31.8 mm / length 95 mm
handlebar KLS CRX 70 RiseBar - diam 31.8 mm / rise 25 mm / width 640 mm (M), 660 mm (L)
grips KLS Token 2Density
seat post KLS Active - diam 27.2 mm / length 350 mm
saddle SELLE ROYAL Vivo
We reserve the right to make changes to the product information contained on this site at any time without notice, including on equipment, specifications, models, colours, and materials.
