Frame set
frame KELLYS e-FRAME City Aluminium alloy monotube, semi-integrated battery, tapered HT, integrated kickstand mount
fork SR SUNTOUR NEX-E25 NLO DS, 63 mm, coil spring
frame size S / M
Drive
motor SHIMANO E5100, 50 Nm, 36 V
battery SHIMANO BT-E8016, 630 Wh / capacity 17.5 Ah
switch unit SHIMANO SW-E6010-L for assist
computer display SHIMANO SC-E6100
crankset SHIMANO E5000 (38T) - length 170 mm
shifters SHIMANO Nexus SL-C7000-5 Revoshift
speed 5
freewheel
18T for internal hub
chain KMC Z1 (102 links)
pedals plastic
Brakes
brakes SHIMANO MT200 hydraulic disc
brake levers SHIMANO BL-MT200
brake rotors 160 mm front / 160 mm rear
Wheels
hubs SHIMANO TX505 / SHIMANO Nexus C7002-5CD 5-speed Internal Geared Hub, Coaster / Disc brake (32 holes)
rims KLS Draft 23 Disc 622x23 (32 holes)
spokes stainless steel black
tyres KENDA Kwick 45x622 (700x45C) ReflectiveLine
fenders
plastic
Cockpit
head parts 1.5 semi-integrated
stem PROMAX a-head adjustable - diam 28.6 mm / bar bore 31.8 mm / length 85 mm (S), 105 mm (M)
handlebar KALLOY RiseBar - diam 31.8 mm / width 640 mm
grips KLS Wave 2Density ergonomic
seat post KALLOY suspension - diam 30.9 mm / length 300 mm (S), 350 mm (M)
saddle SELLE ROYAL Freedom Royalgel
front light
AXA Compactline 35
rear light
TRELOCK Duo Flat
accessories
alloy carrier, adjustable kickstand, bell
We reserve the right to make changes to the product information contained on this site at any time without notice, including on equipment, specifications, models, colours, and materials.
