Frame set
frame
KELLYS Dirt DX 26", 1.5" tapered HT, ISCG 05, sliding dropouts
fork
RST Dirt T (26"), 100 mm, coil spring
frame size
M / L
Drive
crankset
SANOX (32T) - length 170 mm
rear derailleur
SRAM X4
front derailleur
chain guide Mozartt HXR, ISCG 05
shifters
SRAM X5 9-Speed Trigger
speed
9
freewheel
SHIMANO CS-HG200-9 (11-34T)
chain
KMC X9
b.b.parts
SAMOX cartridge
pedals
plastic platform
Brakes
brakes
SHIMANO MT200 hydraulic disc
brake levers
SHIMANO BL-MT200
brake rotors
160 mm front / 160 mm rear
Wheels
hubs
JOYTECH Disc (32 holes)
rims
KLS Asesino 30 Disc 559x30 (32 holes)
spokes
stainless steel black
tyres
SCHWALBE Billy Bonkers 54-559 (26"x2.10) K-Guard
Cockpit
head parts
1.5" semi-integrated
stem
KLS Alm/En 30 - diam 28.6 mm / bar bore 31.8 mm / length 35 mm
handlebar
KLS RiseBar - diam 31.8 mm / rise 30 mm / width 760 mm
grips
kraton
seat post
KLS - diam 30.9 mm / length 300 mm
saddle
KLS Vader
weight
13.34 kg (M)
The weight corresponds to the most common model specification in size M. The actual weight of your bike may vary.
