Frame set
frame
KELLYS Dirt 26, tapered HT, single-speed
fork
X-FUSION Slant RC (26), 100 mm, air / RC Damper / Lock-X 15 mm thru axle
frame size
M / L
Drive
crankset
SAMOX (32T) - length 170 mm
speed
1
freewheel
single speed 15T
chain
KMC Z1
b.b.parts
SAMOX cartridge
pedals
thermoplastic platform
Brakes
brakes
SHIMANO MT500 hydraulic disc
brake levers
SHIMANO BL-MT501
brake rotors
160 mm rear
Wheels
hubs
KT Disc (15x100 mm) / KT Disc single-speed (32 holes)
rims
KLS Brave Disc 559x23 (32 holes)
spokes
stainless steel black
tyres
SCHWALBE Billy Bonkers 54-559 (26x2.21) K-Guard, Classic-Skin, ADDIX
thru axle
X-FUSION Lock-X 15x100 mm front
Cockpit
head parts
FSA 1.5" semi-integrated
stem
RACE FACE Chester 35 - diam 28.6 mm / bar bore 35 mm / 0° / length 40 mm
handlebar
RACE FACE Chester RiseBar - diam 35 mm / rise 35 mm / width 780 mm
grips
dirt
seat post
BMX Pivotal - diam 30.9 mm / length 200 mm
saddle
VELO Pivotal
We reserve the right to make changes to the product information contained on this site at any time without notice, including on equipment, specifications, models, colours, and materials.
