Frame set
frame KELLYS Dirt DX 26", 1.5" tapered HT, ISCG 05, sliding dropouts
fork RST Dirt T (26"), 100 mm, coil spring
frame size M / L
Drive
crankset SANOX (32T) - length 170 mm
rear derailleur SRAM X4
front derailleur
chain guide MOZARTT HXR, ISCG 05
shifters SRAM X5 9-Speed Trigger
speed 9
freewheel
SHIMANO CS-HG200-9 (11-34T)
chain KMC X9
b.b.parts SAMOX cartridge
pedals plastic platform
Brakes
brakes SHIMANO MT200 Hydraulic Disc
brake levers SHIMANO BL-MT200
brake rotors 160 mm front / 160 mm rear
Wheels
hubs JOYTECH Disc (32 holes)
rims KLS Asesino 30 Disc 559x30 (32 holes)
spokes stainless steel black
tyres SCHWALBE Billy Bonkers 54-559 (26"x2.10) K-Guard
Cockpit
head parts 1.5" semi-integrated
stem KLS Alm/En 30 - diam 28.6 mm / bar bore 31.8 mm / length 35 mm
handlebar KLS RiseBar - diam 31.8 mm / rise 30 mm / width 760 mm
grips kraton
seat post KLS - diam 30.9 mm / length 300 mm
saddle KLS Vader
