Frame set
frame
KELLYS THEOS RS-series - Superlight design, advanced robotic welded Al 6061-T6 / Designed & manufactured in EUROPE / Think Link® suspension system, 140 mm rear travel, integrated removable battery, 1.8" tapered HT, post mount 203 mm, mullet 29 / 27.5"+ wheelset, 12x148 mm Boost thru axle
fork
ROCK SHOX Lyric Select (29") Boost, 160 mm, DebonAir+ / Charger RC damper / Maxle Stealth 15 mm thru axle
rear shock
ROCK SHOX Super Deluxe, DebonAir+ / R Hydraulic Bottom Out (210x55 mm)
frame size
M / L
Drive
motor
PANASONIC GXM AMXXPRO - Compact, High Torque & Low weight drive unit, max torque 120 Nm, weight 2.56 kg
battery
KELLYS K2 AMXXPRO CARBON 900 Wh - superhigh energy density 257 Wh/kg, weight 3.5 kg, capacity 25 Ah, co-developed by KELLYS-BMZ
switch unit
PANASONIC
computer display
PANASONIC GXM Center Display 501 - Bluetooth® 5.0 navigation, PANASONIC App conectivity
crankset
MIRANDA Miranda (34T) - length 170 mm
rear derailleur
SHIMANO Deore XT Di2 M8250 (direct mount)
shifters
SHIMANO Deore XT Di2 SW-M8250-IR (I-Spec EV)
speed
12
cassette sprocket
SHIMANO Deore Hyperglide+ CS-M6200-12 (10-51T)
chain
SHIMANO CN-M6100
pedals
plastic
Brakes
brakes
SHIMANO Deore XT M8220 Hydraulic Disc 4-piston
brake levers
SHIMANO Deore XT BL-M8200 hydralic disc
brake rotors
GALFER Fixed Disc Wave® DB134W0 Center Lock, 203 mm front / 203 mm rear
Wheels
hubs
SHIMANO Deore XT M8210-B Disc Center Lock (32 holes)
rims
DT SWISS H 541 Disc 622x30 front / DT SWISS H 541 584x30 rear (32 holes)
spokes
DT SWISS Competition DB black
thru axle
ROCK SHOX 15x110 mm front / 12x173 mm rear
rear tyre
SCHWALBE NOBBY NIC Evo Super Ground 62-584 (27.5"x2.40) TLE, ADDIX SpeedGrip, folding
front tyre
SCHWALBE NOBBY NIC Evo Super Ground 62-622 (29"x2.40) TLE, ADDIX SpeedGrip, folding
Cockpit
head parts
ACROS 1.8" tapered integrated
stem
KLS Alm/En 50 - diam 28.6 mm / bar bore 35 mm / length 35 mm
handlebar
KLS Alm/En 70 RiseBar - diam 35 mm / rise 20 mm / width 780 mm
grips
KLS Silica
seat post
KS Rage-i Remote Telescopic - diam 30.9 mm / length 495 mm, travel 170 mm (M - L)
saddle
KLS Spear Lite
weight
22.98 kg (L)
The weight corresponds to the most common model specification in size L. The actual weight of your bike may vary.
We reserve the right to make changes to the product information contained on this site at any time without notice, including on equipment, specifications, models, colours, and materials.
